Accessories
125
Figure 89 Communication and Charging Cradle - Setup
Installing the Insert
Install the tall insert when using a device without a Rugged Frame or Expansion Back. Install the small insert
when using a device with an Expansion Back and without a Rugged Frame.
1. Align the insert over the pins.
Figure 90 Align Insert with Cradle
2. Press the insert down until it seats flush in the cradle.
Charging the Device
To charge the device in the Communication and Charging Cradle:
1. Open the bottom access door and hold it to the back of the tablet.
2. Align the device with the alignment pins on the cradle.
