Getting Started
17
Installing a microSD Card
To install a microSD card:
1. Press and hold the Power button until the menu appears.
2. Touch Power off.
3. Lift the notched corner of the battery cover and carefully lift the battery cover off the device.
Figure 4 Lifting Battery Cover
4. On the 8.4" version, push the two locking tabs up, then pull up on the tab to remove battery.
On the 10.1” version, push the two locking tabs up (1), then lift the battery up (2).
Figure 5 Removing the Battery - 8.4"
(1)
Locking Tabs
(2)
Pull Tab
