Zebra ET51 User Manual

Wireless
89
• WPS Pin Entry - Touch to connect to a network using Wi-Fi Protected Setup (WPS) pin entry method.
Additional Wi-Fi Settings
NOTE: Additional Wi-Fi settings are for the device, not for a specific wireless network.
Use the Additional Settings to configure additional Wi-Fi settings. To view the additional Wi-Fi settings, scroll
to the bottom of the Wi-Fi screen and touch Wi-Fi Preferences > Advanced > Additional settings.
•Regulatory
• Country Selection - Displays the acquired country code if 802.11d is enabled, else it displays the
currently selected country code.
• Region code - Displays the current region code.
• Band and Channel Selection
• Wi-Fi frequency band - Set the frequency band to: Auto (default), 5 GHz only or 2.4 GHz only.
• Available channels (2.4 GHz) - Touch to display the Available channels menu. Select specific
channels and touch OK.
• Available channels (5 GHz) - Touch to display the Available channels menu. Select specific channels
and touch OK.
• Logging
• Advanced Logging – Touch to enable advanced logging or change the log directory.
• Wireless logs - Use to capture Wi-Fi log files.
• Fusion Logger - Touch to open the Fusion Logger application. This application maintains a history
of high level WLAN events which helps to understand the status of connectivity.
• Fusion Status - Touch to display live status of WLAN state. Also provides information about the
device and connected profile.
• About
• Version - Displays the current Fusion information.

Zebra ET51 Specifications

General

HD type	2K Ultra HD
Display diagonal	8.4 \
Touchscreen type	Capacitive
Display brightness	720 cd/m²
Display resolution	2560 x 1600 pixels
Tcase	100 °C
Tjunction	110 °C
Processor cache	2 MB
Processor cores	4
Processor model	x5-E3940
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom x5 Series
Processor codename	Apollo Lake
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	24 x 31 mm
Number of execution units	12
Processor boost frequency	1.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	9.5 W
Thermal Monitoring Technologies	Yes
Internal memory	4 GB
Internal memory type	LPDDR4-SDRAM
Storage media	eMMC
Compatible memory cards	MMC
Internal storage capacity	64 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Device type	Mobile tablet
Form factor	Slate
Product color	Black
International Protection (IP) code	IP65
Battery voltage	7.6 V
Battery capacity	3300 mAh
Battery life (max)	- h
Battery technology	Lithium
Rear camera type	Single camera
Video capturing speed	30 fps
Video recording modes	1080p
Maximum video resolution	1920 x 1080 pixels
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	2 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Mobile network connection	No
Assisted GPS (A-GPS)	-
Platform	Windows
Operating system installed	Windows 10 IoT Enterprise
Processor ARK ID	96485
Number of built-in speakers	2
HDMI ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	12.7 mm
Width	228 mm
Height	150 mm
Weight	570 g
