Getting Started
View Wireless Status through the Control Panel
11/21/13 P1043301-005
Wireless Signal Indicators Depending on which printer/print engine you are using, press
the following key to access and scroll through the wireless signal indicators on the LCD:
• The right oval for the PA X 4, RPAX4, RXi, RXi HF, and the XiIIIPlus printers/print
engines
•
PLUS (+) for the 105SL, RZ400, RZ600, ZM400, ZM600, Xi4, R110Xi4, 105SLPlus,and
the ZE500 printers/print engines
•
PLUS (+) for the R4Mplus, Z4Mplus, and Z6Mplus printers (supported configurations
only)
• The up arrow for the S4M printer
Table 11 shows the control panel indicators and messages that are associated with the wireless
signal.
Table 11 • Wireless Signal Indicators
Wireless Signal Indicator Description
SIGNAL STRENGTH and
SIGNAL QUALITY
When these indicators display percentages, the wireless radio card is
communicating with the network. The higher the number is, the better
the connection is between the printer and the network.
If your printer indicates a signal strength but you cannot communicate
with the printer from your computer, move the printer to a different
location to try to get a better signal strength or signal quality. This
situation could also indicate that the printer is associated with, but not
authenticated with, your access point.
NOISE LEVEL This number indicates any electrical interference with the wireless
signal.
If your printer cannot communicate with the network and the noise level
is high, move the printer to a location that is free of interference.
