Accessories
145
1-Slot USB Charge Cradle
CAUTION: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 180.
The 1-Slot USB Charge Cradle:
• Provides 5 VDC power for operating the device.
• Charges the device’s battery.
• Provides USB communication with host computer.
Figure 117 1–Slot USB Charge Cradle
Charging the Device
To charge a device:
NOTE: If the device has a Rugged Boot, remove the cup insert before inserting the device. See Integrator Guide for details.
By default, the device includes an interface connector. If the interface connector is removed for USB Type C cable
connectivity, then it must be replaced before charging or receiving an Ethernet IP address if placed in a cradle.
DC Line Cord CBL-DC-388A1-01 Provides power from the power supply
(PWR-BGA12V50W0WW) to the 1-Slot
USB/Charge Only Cradle and 4-Slot Battery
Charger.
2-way DC Cable CBL-DC-523A1-01 Connects one power supply
(PWR-BGA12V108W0WW) to two 4-Slot
Battery Chargers.
US AC Line Cord 23844-00-00R Provide power to power supplies.
Table 13 Accessories (Continued)
Accessory Part Number Description
To Next Page
