5 - 2 TC70x/TC75x Integrator Guide
1. Touch > > About phone.
2. Touch SW components.
3. Touch WWAN five times. The message Turn on SIM Slot UI appears.
4. Touch .
5. Touch .
6. Touch More > Cellular networks > SIM socket selection.
Figure 5-2 SIM Selection Dialog Box
7. Selection the SIM slot to set as default.
WLAN Configuration
Configuring a Secure Wi-Fi Network
To set up a Wi-Fi network:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Wi-Fi.
3. Slide the switch to the ON position.
4. The device searches for WLANs in the area and lists them on the screen.
5. Scroll through the list and select the desired WLAN network.
6. Touch the desired network. If the network security is Open, the device automatically connects to the network.
For all other network security a dialog box appears.
