Accessories 2 - 27
Figure 2-30 Ethernet Proxy Settings
8. In the Proxy hostname field, enter the proxy server address.
9. In the Proxy port field, enter the proxy server port number.
10. In the Bypass proxy for text box, enter addresses for web sites that do not require to go through the proxy
server. Use the separator “|” between addresses.
11. Touch MODIFY.
12. Touch .
Configuring Ethernet Static IP Address
The TC70x/TC75x includes Ethernet cradle drivers. After inserting the TC70x/TC75x, configure the Ethernet
connection:
1. Touch > .
2. Touch Ethernet.
3. Place the TC70x/TC75x into the Ethernet cradle slot.
4. Slide the switch to the ON position.
5. Touch Eth0.
6. Touch Disconnect.
7. Touch Eth0.
8. Touch and hold the IP settings drop-down list and select Static.
NOTE When entering proxy addresses in the Bypass proxy for field, do not use spaces or carriage returns
between addresses.
