Getting Started 1 - 9
Figure 1-16 Lift the Battery
7. Insert the replacement battery, bottom first, into the battery compartment in the back of the TC70x/TC75x.
8. Press the battery down until the battery release latch snaps into place.
9. Replace the hand strap, if required.
10. Press and hold the Power button to turn on the TC70x/TC75x.
Replacing the SIM or SAM Card
To replace the SIM or SAM card:
1. Press and hold the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
4. If hand strap is attached, slide the hand strap clip up toward the top of the TC70x/TC75x and then lift.
CAUTION Replace the battery within two minutes. After two minutes the device reboots and data may be lost.
NOTE SIM replacement applies to TC75x only.
