A - 2 TC70x/TC75x Integrator Guide
Performance Characteristics
CPU 1.8 GHz hex core 64 bit processor (Snapdragon 650/Android-M)
Operating System Android 6.0 Marshmallow
Memory 2 GB RAM/16 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 95% non-condensing
Drop Specification 8 ft./2.4 m to concrete at room temperature; 6 ft./1.8 m over the operating
temperature range
Tumble 2,000 3.2 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing IP67 per applicable IEC sealing specifications
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute
duration per axis, 3 axis
Thermal Shock -40° C to 70° C (-40° F to 158° F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer provides motion-sensing for dynamic screen orientation
and power management
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Wireless WAN Data and Voice Communications (TC75x only)
Frequency band
Worldwide:
LTE: 700,800/850/900/1800/2100/2600 (FDD 28,20,5,8,3,1,7);
UMTS/HSPA/HSPA+: 850/900/1900/2100;
GSM/GPRS/EDGE: 850/900/1800/1900
Americas:
LTE: 700/850/1900/AWS/2100, (FDD 13,12,17,5,26,2,25,4,1);
UMTS/HSPA/HSPA+: 850, 900, AWS, 1900, 2100
GSM/GPRS/EDGE: 850/900/1800/1900;
CDMA: 850,1900 (BC0, BC10, BC1)
GPS Integrated, Autonomous, Assisted GPS (A-GPS), Navstar, GLONASS, Beidou,
Galileo
Table A-1 TC70x/TC75x Technical Specifications (Continued)
Item Description
