Accessories 2 - 33
Figure 2-36 Remove Cup
4. Carefully lift the cup up to expose the cup power cable.
5. Disconnect the cup power cable and USB cable.
Figure 2-37 Disconnect Cup Cables
6. Connect the Battery Adapter power cable to the connector on the cradle.
NOTE Place power cable into adapter to avoid pinching cable.
