Setup
38
3. Place the adapter with an empty core on the take-up spindles and the adapter with the ribbon roll on the
lower supply spindles. The right side of the core adapter fits on the cone tip on each of the spring
loaded right side spindles. Continue pushing the adapter onto right side spindle and swing the adapter
onto the left side spindle hubs. Rotate the adapters and hubs until the until notches on the adapters
flange align and lock ton the left spindles hub spokes.
