OPERATION
Axio Observer TFT display touchscreen on the Axio Observer 7, 7 materials ZEISS
12/2016 431004-7244-001 117
Navigation bar Tabs in the control area
1st level
Home
2nd level 3rd level
Home
see page 118
Magnifi-
cation
Colibri-LEDs Contrast
Virtual
reflector
Light path F/A
MAT
(materials)
Microscope
see page 121
Control
see page 121
Objectives Colibri-LEDs Reflector
Virtual
reflector
Optovar Light path F/A Bio / Med
Automatic
see page 126
Soft keys
XYZ
see page 127
Position Measure
Definite
Focus
Incubation
see page 130
Incubation Y module Bio / Med
Settings
see page 131
Components
see page 131
Objectives Reflector Focus Stage
Camera
ports
Misc
User
see page 138
Mode
Buttons
left
Buttons
right
Stand type Language
Docking
station
Extras
see page 141
Light
Manager
Oil stop
Dazzle
protection
Ethernet Misc
Info
see page 143
Firmware
Display
see page 143
Fig. 94 Menu overview
