Stereo microscope INTRODUCTION
Stemi 305 Warranty notes ZEISS
01/2015 435063-7044-001 11
Fig. 1 Warning and information labels on the device
1 LED aperture, transmitted-light illuminators
2 LED aperture, spot illuminator K LED
3 LED aperture, ring illuminator K LED, segmentable
4 LED aperture, double spot illuminator K LED
5 LED aperture, integrated vertical illuminator
Fig. 2 Warning labels and apertures for LED radiation
