Zerotech YS-S4 User Manual

YS-S4 Multi-rotor Autopilot User Manual V1.4
11



Adjustyourtwo‐wayswitchendpointstocontroltheflightmodes:
CH5Position CH6Position GPSStatus WorkingMode
Position1 Position1 X ManualStabilization
Position2 Position1 GPSNoLock ManualAltitudeHold
GPSLock（above5satellites）
AutoHover
X Position2
GPSLock（above5satellites）
ReturnandLand
IMPORTANT:
ReturnandLandmodealwaystakespriority.InanymodetheautopilotwillperformtheReturnandLand
operationifCH6isswitchedtoposition2.

Step2Fail‐SafeSetup(F/S)

Thereare2waysofsettingupF/S:defaultmodeandoptionalmode

1)DefaultF/Smode

Checkwith
yourRadiomanualonhowtosettheReceiverfailsafe.EnsurethatwhenyouturnOFFyourradio,
yourfailsafesettingsareasfollows:
 CH5settoposition2
 CH6settoposition2
 THRset50%(mid‐point)

DefaultF/SonlyhasReturnandLandmode
whichmeanstheYS‐S4willcommandtheaircrafttoReturnandLand
automaticallyifthecommunicationbetweentheTXandtheautopilotisdisconnected.

2)OptionalF/SSetup

IMPORTANT
1) ThisonlyappliestoFUTABAtransmitters.
2) “OptionalF/S”isnotrecommendedforbeginnersbecausethesettingprocedureis
verycomplicated.

EnsurethatwhenyouturnOFFyourradio,yourfailsafesettingsareasfollows:
 CH5issettoposition2
 CH6issetto50%(mid‐point)
CH5Position1—ManualStabilizationMode
CH5Position2—AutoMode
CH6Position1—Neutral
CH6 Position2 — Return and Land
