LEDIndicatorInterpretation:
TheworkingstatusoftheS4isbasicallyindicatedbytheGREEN+REDLEDs,seebelow:

FlightStatus LEDstatus Description
Manual（GPSNOTLOCKED）
 1secondGREENand1secondRED
Manual（GPSLOCKED）
 2secondsGreenonceperloop

Manualaltitude‐hold 2secondsGREENand1secondRED
Auto‐hover 3secondsGREEN
Firststagelowvoltagealert

 2secondsRED
Finalstageurgentlowvoltagealert

 3secondsRED
ReturnandLand ContinuousREDflashing

Magneticcompasscalibration

 ContinuousGREENflashing

IMUError ContinuousYELLOWflashing


TheautopilotcancalculatethelowvoltagealertaccordingtotheCellNumberfilledinbytheuser.“Finalstage
lowvoltagealertNumber”=(Voltagepercell‐0.05v)*CellNumber
E.g.voltagepercell3.7‐0.05v=3.65multipliedbycellnumber=totalvoltage(14.6vfor4cells)

When
thefinallowvoltagealertisindicated,thecraftwillland(Youcanadjustthelandingpositionduring
landingbutmakesureyouDONOTpushtheTHRstickduringthisoperation.)
