AftertheCSCoperation,pushtheTHRstickslightlyup.Themotorsshouldbegintoturn.Youneedtoapplymore
throttletotakeoffnormally.
7.3 MotorMixerChecking
Beforetake‐off,youstillneedtocheckyourmotormixcontrol.

Firstlet’stakethequadcopter+typeasanexampletosimplydescribehowtocheckmotormixcontrol(Please
refertotheillustrationforotheraircraftconfigurations).Youneedtoarmthemotorsandcheckwhathappens
when
youadvancethethrottlestick,ifthefourmotorsrotateatthesamespeedthismeansthemotorbalanceis
good.

1.Tochecktheaileronchannel,slightlypushtheaileronsticktotheleft,motorM4shouldrotateimmediately
(see1ontheillustrationbelow),theotherthreemotors
shouldkeepstill.Pushtheaileronsticktotheright
slightly,motorM2shouldrotateimmediately(see2ontheillustrationbelow),theotherthreemotorsshould
keepstill.

2.Checktheelevatorchannel.Accordingtotheaircraftsymmetryitshouldbesimilartocheckingtheaileron
channel.Pushtheelevator
stickupslightly,motorM3shouldstarttorotate(see3ontheillustrationbelow)now
slightlypulltheelevatorstickdownandmotorM1shouldstarttorotateimmediately(see4ontheillustration
below).

QuadcopterXtype
