CheckthatthedisplayofeachstickshowsthatTXiscalibratedwell.Thisscreendisplaysthepositionofthesticks.
OntheleftistheRudderandElevator(Mode1depicted).OntherightistheaileronandTHRstick(Mode1
depicted).

WhenbothsticksareinthemiddlepositiontheyareshownasGREEN,anyotherpositionshowsREDexceptfor
whenthethrottlestickisatthebottomwhenitshowsasYELLOW.Whenthethrottleisinhoverposition
(normallyclosetothemiddleposition)itshowsGREEN,otherflyingstatusshowsRED.

6.4.2 TXCalibrationbyPhone
Step1Selectthecorrectsticklayout(Mode1,Mode2,Mode3etc.)

1) Clickthemenubuttononyourphonethenselect"Set”(seebelow)



2) Inthe"Set"boxwhichopensselectthe"HandMode"drop‐downmenu.The“HandMode”isyour
transmittermode(Mode1,Mode2,Mode3etc.)


