YS-S4 Multi-rotor Autopilot User Manual V1.4
6

4. Installation
4.1YS‐S4ModuleInstallation
1) TheYS‐S4Moduleshouldbeplacedlevelonthemainbodyoftheaircraft.
2) ForbestresultsinstallattheCenterofGravity(CoG)oftheaircraft.
3) The“FrontArrow”MUSTpointtowardstheheadoftheaircraft:

 
IMPORTANT:
TheYS‐S4willadapttomostaircrafttypeswithoutinnerdampening.Itmaynotadaptsatisfactorilytolarger
aircraftinwhichcasetheYS‐S4shouldbemounte dontheoptionaldampeningstructureshownbelowand
availablefromZeroUA V.

YS‐S4dampeningstructure
4.2GPSModuleInstallation
1) Ensurethatthestickerfacesupandthearrowpointstowardstheheadoftheaircraft.Otherwisetheaircraft
mayflyincircleswheninauto‐hovermode.


2) TheGPSmoduleshouldbeinstalledon alevelGPSstand,
mountedhigherthantheelectricalcomponentson
theaircraft.Thisensuresminimalmagneticfieldeffectfromtheotheron‐boardcomponents,suchaspower
cables,transmitters,motors,ESCsandcamera.




Arrowtowards
aircrafthead
Towards aircraft nose
