Zerotech YS-S4 User Manual

YS-S4 Multi-rotor Autopilot User Manual V1.4
23


Hexacopt er+type：

Hexacopt erXtype：


8. Tasks
8.1 ServoGimbal
PoweringtheservoswhenusingagimbalwiththeS4:









ConnectY1tothegimbalrollservoandY2tothegimbalpitchservo.Enter“RollSensitivity”and“Pitch
Sensitivity”intheParameterSectionoftheGCStoadjustthecorrectionangleanddirectionofyourgimbal.
GimbalSensitivity
rangesfrom‐127to127.Anegativenumberreversesthedirectionoftravelandthesizeofthe
numberaffectstheamountofcorrection.
GND
VCC
Signal
ServoBattery
GimbalServo
Y1/Y2
Connector
