5. Put the intermediate gear onto the tapered
r
oller bearing.
Fig. 203
6. Slide the tapered roller bearing onto the
bear
ing bolt.
Fig. 204
7. Put shim with e. g. s = 2.80 mm onto the
bear
ing bolt.
Fig. 205
Assembly
