ZF AV 110 - Standard Tools and Fixtures

Figure Order no.
Designation
Chap
ter/section
Quantit
y
Comment
5870.204.044
Locating pin
▪
Ins
tall mounting parts, page 129
1 1 set = 2 units
M20 x 1.5 x 95
7.2 Standard tools and fixtures
To repair this ZF product use the following standard tools and fixtures.
S
tandard tools:
Figure Order no.
Designation
Comment
Fig. 2
5870.203.030
T
orque wrench
0.6 Nm to 6.0 Nm
5870.203.031
T
orque wrench
1.0 Nm to 12 Nm
5870.203.032
T
orque wrench
3.0 Nm to 23 Nm
5870.203.033
T
orque wrench
5.0 Nm to 45 Nm
5870.203.034
T
orque wrench
10 Nm to 90 Nm
5870.203.039
T
orque wrench
80 Nm to 400 Nm
5870.203.016
T
orque wrench
140 Nm to 750 Nm
5870.203.011
T
orque wrench
750 Nm to 2,000 Nm
5870.203.048
T
orque wrench
1,500 Nm to 3,000 Nm
Fig. 3
5870.900.013
Se
t of internal pliers
Contains the sizes:
I1, I2, I3, I4
Workshop Equipment
30
EN 4472.751.001 - 2015-11
