ZF AV 110 - Page 29

Figure Order no.
Designation
Chap
ter/section
Quantit
y
Comment
5870.260.004
Handle
▪
Assembling hub, pag
e 120
1 Length 230 mm
5870.345.121
Suppor
t arbor
▪
Assembling hub, page 120
1
AA00.607.922
Dr
iver tool
▪
Assembling hub, page 120
1
5870.651.085
Assembl
y aid
▪
Install hub, page 124
1
5870.204.029
Locating pin
▪
Ins
tall hub, page 124
1 1 set = 2 units
M18 x 1.5 x 105
