Figure Order no.
Designation
Comment
Fig. 18
5870.200.066
Se
t of parallel gauge blocks
Consisting of two pieces
Height 70 mm
5870.200.067
Se
t of parallel gauge blocks
Consisting of two pieces
Height 100 mm
Fig. 19
5870.200.109
Digit
al caliper gauge
Length 150 mm
Fig. 20
5870.200.072
Digit
al depth gauge
Length 200 mm
5870.200.114
Digit
al depth gauge
Length 300 mm
Tab. 2
Fixture Comment Requirement
Crane with precision hoist Load-bearing capacity min. 1,500 kg
Arbor press Manual operation Press force max. 30 kN
Hydraulic press Hydraulic actuation
Tab. 3
Other Equipment Comment Requirement
Socket wrenches, open-end wrenches,
bo
x wrenches, hammers, screw drivers,
pliers, front cutting pliers
Various sizes, respectively in a set Commercial
Sand paper In different grit sizes to clean surfaces
Flat scraper For removal of sealing compound
Whetstone For removal of minor damage and smoothing of plane
f
aces
Polishing cloth For smoothing and cleaning of surfaces
Foam roller When applying sealing compound
Tab. 4
Workshop Equipment
34
EN 4472.751.001 - 2015-11
