ZF AV 110 - Remove Breather

33. Use 5870.300.007 [Extracting device] and
5870.300.003 [Extr
acting device] to pull the
bushes (thrust washers) out of the portal
housing.
Fig. 75
34. Use AA01.305.639 [removing tool] to loosen
t
he stud bolts.
Fig. 76
8.8 Remove breather
1. Open hose clamp (1).
2. Pull corrugated hose and hose (2) from the
breather neck.
3. Loosen Torx screws (3) and remove breather.
Fig. 77
Dismantling
EN 4472.751.001 - 2015-11
57
