6.
Tighten screws, if the parts have max.
30 °C
.
Fix differential. Bolt in N
ew Locking screws
and tighten crosswise.
Tightening torque: 250 Nm
Fig. 138
7. Insert bearing outer ring with
AA02.015.690 [Dr
iver tool] and
5870.260.002 [Handle] until contact is
obtained.
Fig. 139
8. Press in bearing inner ring with
AA02.056.505 [Pr
essure piece] until contact
is obtained.
Fig. 140
Assembly
80
EN 4472.751.001 - 2015-11
