ZF AV 110 - Page 89

2. Apply 0666.690.078 [Sealing compound] to
t
he short thread of the stud bolts.
3. Use AA00.593.346 [Screwing device] to bolt
the stud bolts with the short side to the portal
housing.
Tightening torque: 33 Nm
Fig. 158
4. Use AA02.041.179 [Driver tool] and
5870.260.002 [Handle]
to insert the bushes
(thrust washers) into the portal housing.
Fig. 159
5.
In case of used bearings, always
allocat
e the bearing inner rings to the
respective bearing outer rings.
Slide the tapered roller bearing onto the
bear
ing bolt.
Fig. 160
Assembly
EN 4472.751.001 - 2015-11
89
