0...100 % PWM (factory setting)
Control via external setting signal PWM
E1.1
PWM
E1 D1 GND 10V
Analog In 1 10 V DC Out
13.06.2014
i_jumper_motor_mounted_pwm.eps
24V
24 V DC Out
24 V
15...28 V
+
-
GND
E1
E1.1
PWM
(10 V)
E1
D1 GND
10V
Analog In 1 10 V DC Out
24V
24 V DC Out
PWM
f = 1...10 kHz
10 kΩ
0...20 mA
Control via external setting signal 0...20 mA
E1
D1 GND
0...20 mA
+
Analog In 1
E1.1
mA
13.06.2014
i_jumper_motor_mounted_0_20ma.eps
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Electrical installation
L-BAL-E300-GB 1905 Index 001 Part.-No.
32/48
