ZIEHL-ABEGG PMIcontrol Basic-M Series User Manual

Connection data terminals relays
FSDM5/7.5/8.5 FSDM12/17/25/32/39/46
Stripping length 10 mm 5...6 mm
Min. conductor cross-section solid 0.2 mm
2
0.08 mm
2
Max. conductor cross-section solid 2.5 mm
2
2.5 mm
2
Min. conductor cross-section flexible 0.2 mm
2
0.08 mm
2
Max. conductor cross-section flexible 2.5 mm
2
2.5 mm
2
Min. conductor cross-section flexible with wire
end ferrule
0.2 mm
2
0.25 mm
2
Max. conductor cross-section flexible with wire
end ferrule
2.5 mm
2
1.5 mm
2
Min. conductor cross-section flexible with wire
end ferrule and collar
0.2mm
2
0.25 mm
2
Max. conductor cross-section flexible with wire
end ferrule and collar
2.5 mm
2
1.5 mm
2
Min. conductor cross-section AWG AWG 26 AWG 28
Max. conductor cross-section AWG AWG 12 AWG 12
Connection data terminals control
FSDM5/7.5/8.5 FSDM12/17/25/32/39/46
Stripping length 9 mm 8 mm
Min. conductor cross-section solid 0.14 mm
2
0.2 mm
2
Max. conductor cross-section solid 1.5 mm
2
1.5 mm
2
Min. conductor cross-section flexible 0.2 mm
2
0.2 mm
2
Max. conductor cross-section flexible 1.5 mm
2
1.5 mm
2
Min. conductor cross-section flexible with wire
end ferrule
0.25 mm
2
0.25 mm
2
Max. conductor cross-section flexible with wire
end ferrule
1.5 mm
2
1.5 mm
2
Min. conductor cross-section flexible with wire
end ferrule and collar
0.25mm
2
0.25 mm
2
Max. conductor cross-section flexible with wire
end ferrule and collar
1 mm
2
0.75 mm
2
Min. conductor cross-section AWG AWG 26 AWG 24
Max. conductor cross-section AWG AWG 16 AWG 16
5.3 EMC-compatible installation
5.3.1 Control cables
Pay attention to sufficient distance from powerlines and motor wires to prevent interferences. The
control cable may not be longer than 30 m. Screened control cables must be used when the cable
length is longer than 20 m. When using a shielded cable connect the shielding to one side only, i.e.
only to the control unit with the protective ground (keep cable short and with as little inductance as
possible!).
5.3.2 Harmonics current for devices ≤ 16 A
According to EN 61000-3-2 these devices are to be classified as “professional” devices.
Connection to a low voltage supply (public networks) is allowed insofar as this has been clarified with
the respective energy supply company responsible.
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Electrical installation
L-BAL-E300-GB 1905 Index 001 Part.-No.
28/48
