8.1.1 Maximum loading dependent on switching frequency, line voltage and ambient temperature
The maximum permissible temperature for the rated current at rated voltage and rated clock frequency
is specified as rated temperature.
Since the dissipation of the power loss (heat development) in the device is decisively dependent on
the ambient temperature, the max. load must be reduced at an ambient temperature above the rated
temperature (see following table)!
The measured average value over 24 hours must be 5 K below the max. ambient temperature.
Since the power loss in the device increases with rising line voltage, the following table must be
observed.
Maximum motor current at 8 kHz (factory setting) depending on line voltage and ambient
temperature
Type
208 V (-15 %)...415 V (+6 %)
over 415 V (+6 %)...480 V (+10 %)
40 °C 50 °C 55 °C 40 °C 50 °C 55 °C
FSDM5
5,0 A 5,0 A 5,0 A
5,0 A 5,0 A 5,0 A
FSDM7.5
7.5 A 7.5 A 6.8 A
7.5 A 7,0 A 6,4 A
FSDM8.5
8.5 A 7.6 A 6.8 A
8.5 A 7,0 A 6,4 A
FSDM12
12.0 A 12.0 A 12.0 A
12.0 A 12.0 A 12.0 A
FSDM17
17.0 A 17.0 A 16.0 A
17.0 A 16,5 A 15.5 A
FSDM25
25.0 A 25.0 A 25.0 A
25.0 A 25.0 A 25.0 A
FSDM32
32.0 A 32.0 A 30.5 A
32.0 A 30.5 A 29.0 A
FSDM39
39.0 A 36.0 A 32.0 A
39.0 A 34.5 A 30.5 A
FSDM46
46.0 A 36.0 A 32.0 A
46.0 A 34.5 A 30.5 A
For 16 kHz not specified yet!
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Enclosure
L-BAL-E300-GB 1905 Index 001 Part.-No.
41/48
