Digital input “D1” Input resistance: R
i
approx. 4 kΩ
Voltage range high level: 10....30 V DC
Voltage range low level: 0....4 V DC
Open-Collector output “OC” I
max
: 20 mA
U
CE max
: 30 V DC
Max. contact rating of the relay 2 A / 250 V AC
Max. permissible ambient tempera-
ture for operation
55 °C
Min. permissible ambient tempera-
ture for operation
0 °C (if mains voltage is not switched off up to -20 °C)
Permissible temperature range for
storage and transport
-30...+80 °C
Permissible installation height 0...4000 m amsl
≤ 1000 m: no limitation
> 1000 m: max. permissible output current = current indication name plate
minus 5 % / 1000 m
> 2000 m: max. permissible line voltage = max. voltage indication name
plate minus 1.29 % / 100 m
UL note:
Use in an earthed triangle system (see electrical installation) ≥ 2000 m
above sea level is not allowed!
Permissible rel. humidity 85 % no condensation
Electromagnetic compatibility for the
standard voltage 230 / 400 V ac-
cording to DIN IEC 60038
Interference emission EN 61000-6-3 (domestic household applications)
For 16 kHz switching frequency according EN 61000-6-4 (industrial appli-
cations)
Interference immunity EN 61000-6-2 (industrial applications)
Harmonics current For devices ≤ 16A according to EN 61000-3-2 (see Electrical Installation /
Harmonics current for devices ≤ 16 A)
For devices > 16 A and ≤ 75 A according to EN 61000-3-12 (see Electrical
Installation / Harmonics current and line impedance)
Max. leakage current according to
the defined networks of
DIN EN 60990
FSDM5/7.5/8.5 approx. 3 mA
FSDM12/17 approx. 5 mA
FSDM25/32 approx. 2 mA
FSDM39/46 approx. 3.4 mA
Vibratory strength
Broadband noise (simulated life-endurance test) in accordance with
EN 61373, category 1 class B.
Shock test according to EN 61373, category 1
Housing protection
IP54
* Regarding the mains connection, these devices are to be classified as category “C2” devices according to the relevant
EN 61800-3. The increased requirements placed on electrical interference > 2 kHz for category “C1” devices are complied
with in addition.
** Factory setting (possible setting by add-on module for communication).
Authorization: FILE No.
E213826
UL61800-5-1
CAN/CSA C22.2 No.
274
Power Conversion
Equipment
62BN
•
Enclosure rating: Type 1
•
Use in a Pollution Degree 2 enviroment
During the UL evalution, only Risk of Electrical Shock and Risk of
Fire aspects were investigated, Functional Safety aspects were not
evaluated.
Additional Information see Online Certifications Directory:
https://iq.ulprospector.com/info/?utm_source=ocd&utm_medium=banner&utm_campaign=piq-soon
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Enclosure
L-BAL-E300-GB 1905 Index 001 Part.-No.
40/48
