ZIEHL-ABEGG PMIcontrol Basic-M Series User Manual

8.2.2 UL: Overload protection
The devices are equipped with a solid state motor overload protection and a solid state short circuit
protection.
The solid state motor overload protection protects the motor under overload conditions by reducing
current flow to the internal motor output terminals. This protection is achieved through algorithms
based on I
2
t of the current of the motor.
The overload protection circuitry is optimally configured to the specific motor and the specific final
application of the integrated variable speed drive. This is typically 100 % of the full-load current of the
motor.
The solid state short circuit protection acts to suspend current flow to the internal motor output
terminals upon sensing output current and DC-link voltage. The protection of the motor is comprised
of hardware and firmware.
8.2.3 UL: Short Circuit Current Rating
The devices are suitable for use in a circuit capable of delivering no more than 30/100 kA RMS
symmetrical (see also information sign on product). Details can be found in the following table.
The fusing for the short-circuit protection must comply with the requirements in UL248 and additional
to CAN/CSA C22.2 No. 248.
Tests were made with RK fuses without semiconductor protection:
Maximum sym-
metrical current
Protection rating Maximum AC
Voltage
Rating of Fuse Type frequency inverter
100kA RMS RK5 240 V 10 A / 250V
(e.g. Mersen TR10R)
FSDM5
100kA RMS RK5 480 V 10 A / 600V
(e.g. Mersen TRS10R)
100kA RMS RK5 240 V 12 A / 250V
(e.g. Mersen TR12R)
FSDM7.5
100kA RMS RK5 480 V 12 A / 600V
(e.g. Mersen TRS12R)
100kA RMS RK5 240 V 12 A / 250V
(e.g. Mersen TR12R)
FSDM8.5
100kA RMS RK5 480 V 12 A / 600V
(e.g. Mersen TRS12R)
30kA RMS RK5 240 V 16 A / 250V
(e.g. Mersen TR16R)
FSDM12
30kA RMS RK5 480 V 16 A / 600V
(e.g. Mersen TRS16R)
30kA RMS RK5 240 V 20 A / 250V
(e.g. Mersen TR20R)
FSDM17
30kA RMS RK5 480 V 20 A / 600V
(e.g. Mersen TRS20R)
30kA RMS RK5 240 V 35 A / 250V
(e.g. Mersen TR35R)
FSDM25
30kA RMS RK5 480 V 35 A / 600V
(e.g. Mersen TRS35R)
30kA RMS RK5 240 V 35 A / 250V
(e.g. Mersen TR35R)
FSDM32
30kA RMS RK5 480 V 35 A / 600V
(e.g. Mersen TRS35R)
30kA RMS RK5 240 V 50 A / 250V
(e.g. Mersen TR50R)
FSDM39
30kA RMS RK5 480 V 50 A / 600V
(e.g. Mersen TRS50R)
30kA RMS RK5 240 V 50 A / 250V
(e.g. Mersen TR50R)
FSDM46
30kA RMS RK5 480 V 50 A / 600V
(e.g. Mersen TRS50R)
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Enclosure
L-BAL-E300-GB 1905 Index 001 Part.-No.
43/48
