Integrated solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes, or the equivalent.
8.2.4 Short Circuit Current Rating (SCCR)
The short circuit current rating (SCCR) is dependent on the device type and article number (see also
name plate and type key chapter).
Type Short Circuit Current Rating (SCCR)
FSDM5 100 kA
FSDM7.5 100 kA
FSDM8.5 100 kA
FSDM12 30 kA
FSDM17 30 kA
FSDM25 30 kA
FSDM32 30 kA
FSDM39 30 kA
FSDM46 30 kA
Operating Instructions PMIcontrol Basic-M – model series FSDM5...46 Enclosure
