Page 20 of 40 801910 - Zip Sparkling HydroTap - Installation Instructions - July 2014 - v1.00
Typical Cut out arrangement
for Chilled Sparkling models
with kickboard venting via a
left hand appliance duct
Typical Cut out arrangement
for Boiling Chilled Sparkling
models with kickboard
venting via a right hand
appliance duct
A
A
B
C
B
C
Ventilation
2.2 Chilled Sparkling ventilation
2.3 Boiling Chilled Sparkling ventilation
