Page 8 of 40 801910 - Zip Sparkling HydroTap - Installation Instructions - July 2014 - v1.00
Before Installation
Before installing ensure that the following have been
provided at the Installation site:
•
Review all the technical specifications.
•
Ensure the underbench can support the product weight when full of water
(allow an extra 5-8kg when full. )
•
Sufficient space in the cupboard to install all of the underbench units
in accordance with these Installation Instructions. Refer to technical
specification for dimensions. Make allowance for a booster heater and
/ or water softener if required. Refer to section 3 & 4, for Installation
instructions.
•
For Zip HydroTap CS 175 and all 160/175 models, a 220-240Vac, 10A
GPO will be required. For Zip HydroTap 240/175 models, two 220-
240Vac, 10A GPOs will be required. (One GPO is for the Zip HydroTap
and the other for the Booster heater).
NOTE: Check all cable and hose lengths against inlet /outlet
positions before proceeding (See section 6 for general layout).
•
A potable water supply connection with isolating valve inside the
cupboard within reach of the braided hoses and positioned so that the
connection point and the stop cock will not be obstructed when the
underbench units are installed.
•
For the mains pressure All-IN-ONE, an external hot and cold water supply
will be required.
•
If an external filtration or water softening device is required, then it is
important to allow extra space for these items.
•
A cold water supply with a minimum working pressure of 172kPa and a
maximum working pressure of 700kPa connected via an isolation valve.
•
The fitting of an air flow duct, attached to the side of the unit, requires a
rectangular cut size of 284mm x 45mm, to provide adequate warm air
displacement. See section 2.
•
The appliance must be placed with it’s base in a horizontal position.
IMPORTANT!
Do not proceed with the Installation if these requirements are
not met.
