Zip HydroTap BCS160 - Model 5-In-1 Vented

801910 - Zip Sparkling HydroTap - Installation Instructions - July 2014 - V1.00 Page 33 of 40
Installation Instructions
6.7 Model HydroTap 5-In-1 Vented
Note: The connection tubes supplied with the Tap, Booster and Ext filter/ softener CANNOT be lengthened.
HydroTap
Mixer
Connections
RED
BRAIDED
Note: All
plastic tubes
must be cut to
size. They must
have a constant
fall back to the
unit.
Tee piece and
Restricta! ow
valve (supplied)
External COLD
isolation valve
(Not Supplied)
GAS IN
POWER
CORD
USB
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
SPARKLING
OUTLET
CO2
IN
BLUE
Booster
option
Booster
CLEAR
WHITE
Note:
- Mains hose
length is 750mm
- Plug and Cord
length is 1800mm
Position the
underbench unit
according to the
hose and cord
lengths supplied
