SW3
GIGABIT/FAST ETHERNET SWITCH TYPE SW3 (DIN) 11/122
USER GUIDE - M0SW3D1905Iv04 - V04 May 2019
1.4 TECHNICAL SPECIFICATIONS
1.4.1 Switch characteristics
➢ Full Duplex Wired Speed switching core.
➢ Port speed automatic detection.
➢ STP and RSTP for resolving loops in the network and operation in rings.
➢ Multiple VLANs management (250 simultaneously).
➢ QoS:
•
the SW3 can use the priority fields included in the IEEE 802.1p tag,
•
as well as the DSCP identifier included in the IP header.
➢ Broadcast and Multicast (Broadcast Storm Control) traffic limitation.
➢ MAC access control lists and 802.1x user authentication.
➢ Q-in-Q operation (double-tagged).
➢ Link aggregation by LAG function, static, according to IEEE 802.1ad.
➢ Port mirroring.
➢ Links in VLAN Native mode.
➢ Interoperability with IEDs (Intelligent Electronic Device) that complies with the
IEC 61850 requirements.
1.4.2 Equipment interfaces
➢ Up to 8 Fast Ethernet front ports, which are the result of the combination of:
•
8 ports in 10/100Base-Tx configuration with RJ-45 connector, or
•
4 ports in 10/100Base-Tx configuration with RJ-45 connector and
4 ports in 100Base-Fx multimode (1300 nm) configuration
with MT-RJ or, upon request, LC or ST connector.
➢ 1 service console (DCE mode).
➢ 2 front Gigabit Ethernet SFP bays (see section 1.4.3).
1.4.3 Accessories
➢ SFP Gibabit/Fast Ethernet SFP modules.
The following list corresponds to verified modules, which comply with the temperature
criteria.
•
SPF 10/100/1000BaseT (4CZ07980012)
type of connector: RJ-45
•
SFP 1000BaseT (4CZ07980001)
type of connector: RJ-45
