SW3
GIGABIT/FAST ETHERNET SWITCH TYPE SW3 (DIN) 31/122
USER GUIDE - M0SW3D1905Iv04 - V04 May 2019
Changes made with the set command are not operative merely because they have been
executed. Effective, immediate use of the changes made is achieved by running the
Apply command. On the contrary, the Save commands entails storing the changes
made permanently, without requiring their immediate use, but applied in the case of an
initialisation.
In this way, the changes are implemented as an operating procedure through the Apply
command, and after checking that the behaviour is correct, it is saved using the Save
command. Consequently, in the case of obtaining undesirable results, it is always
possible to eliminate the Save command and reboot the equipment to recover the
previous status, even in the case that the changed activated lead to the user not being
able to obtain access.
Access can also be obtained to the console remotely through SSH connection and Telnet.
4.2 HTTP SERVER
The HTTP server included provides access to the HTML pages giving access to all the
configuration data.
The procedures for the effective configuration of the parameters are identical, that is to
say, it is necessary to execute the Apply command and/or the Save command, as
indicated in the section on using the console, but before running these commands, the
system must be informed that the data have been changed through the Send command
(the button is present in all the HTML pages).
The Apply and Save commands are at the bottom of the tree menu and are only visible
when the user profile has administration rights. FIGURE 18 shows commands indicated.
For information about the Reboot, Reflash, Configuration files and Event files
commands see sections 5.17, 5.18, 5.19 and 5.20 respectively.
The Apply, Save and Reboot commands request confirmation of the operation from the
user before it is actually executed.
