SW3
GIGABIT/FAST ETHERNET SWITCH TYPE SW3 (DIN) 37/122
USER GUIDE - M0SW3D1905Iv04 - V04 May 2019
The third parameter, Syslog Log, is a CheckBox control. Sending the data to a Syslog
remote server means that no information is stored locally. This parameter allows local
storage to be active simultaneously with external sending, with its own severity level
independent of the one used for the remote server. By default, it is NOT selected, which
means that a remote server is configured and the traces are NOT stored in the local Log.
The last parameter, Syslog Server IP, selects the IP address of the Remote Syslog server
to which the information is sent.
The system can order the selective activation/deactivation of log information associated
to some operating blocks (see command log).
Through CLI it is possible to consult the local log files other than the current one (see
command show).
5.2 ADMINISTRATION
The equipment has an integrated HTTP server for management purposes. The server
supports the HTTP and the HTTPS protocols, and users can selectively enable their use
and the respective port.
The equipment also allows to enable FTP and FTPS separately.
The path that is accessed by FTP within the router is the var / plog where the files can be
found:
• Auth
• Auth.0
• Conf.txt
• Conf.xml
• Customer.txt
• Events
• Messages
• Messages.0
• Messages.1
• Messages.2
• Messages.3
• Security
• Security.0
The credentials for accessing the FTP folder are the same as for accessing the equipment.
