SW3
GIGABIT/FAST ETHERNET SWITCH TYPE SW3 (DIN) 32/122
USER GUIDE - M0SW3D1905Iv04 - V04 May 2019
FIGURE 18 HTML page tree menu
In the HTML pages the commands for adding and removing elements from the tabled data
are explicitly shown as buttons labelled Add and Delete, located on each of the objects that
use them.
The factory IP address of the equipment is 192.168.0.1, meaning it is possible to access
the HTTP server to configure it from the very start (see chapter 5).
It should be borne in mind that if the IP address is changed, the IP address of the client
equipment must also be changed accordingly.
