SW3
GIGABIT/FAST ETHERNET SWITCH TYPE SW3 (DIN) 92/122
USER GUIDE - M0SW3D1905Iv04 - V04 May 2019
Run the Call option of the Call menu. Pressing return, a window is shown in which the swt
login: prompt will appear, ready for the user to enter the login and code for starting the
session (the logins and their respective passwords are the same as in the web interface).
Remember that no text will appear in the HyperTerminal window when entering the
password.
As operating systems like Microsoft Windows 7© no longer include the HyperTerminal
program, the Putty program, free and executable, is also considered.
The Putty program is accessible on the www.putty.org web. Simply select the Putty that
suits the operating system in use (usually the first, called putty.exe), copy it in the PC and
run it.
FIGURE 58 Putty home window
In the Serial menu (last of all) the serial port is configured.
If an USB converter is used, first, consult the COM number in the Device administrator
(Control panel).
