H.264 Super Digital Video Recorder User Manual
54
the channel name. The 16 Chinese characters and 25 letters are supportive.
Time title: means the selective state. Display the system data and time in the surveillance
window.
Channel title: means the selective state. Display the system channel number in the
surveillance window.
Recording status: means the selective state. Display the system recording status in the
surveillance window.
Alarm status: means the selective state. Display the system alarm status in the surveillance
window.
Deflick: select , enable this function.
Channel: select the channel number which needs to have region cover
Region cover: select , enable this function. Click region button, enter relative channel, user can
choose the size of region cover, a channel can maximum set four regions (the video
output is black of the covered region)
【record overlay】
Time tile: select , enable this function. Show time and date on screen overlay
Channel title: select , enable this function, show channel title on screen overlay.
Position setting: adjust position of time title and channel title of screen.
4.7.4 Backup
You can backup the video files to external storage through setup.
Note：The storage must be installed before the file backup. If the backup is terminated, the already
copy files can be playback individually. If the backup is stop midway, the already copy files also can be
playback individually.
Picture 4.41 Backup
Detect: Detect the storage connected with the DVR such as hard disk or universal disk.
Backup: Click “backup” button and the dialog box is popped up as picture 4.41. You can choose
