H.264 Super Digital Video Recorder User Manual
6
2. Open-package check, Products understanding and cable connection
2.1 Open-package check
When you receive the DVR, please check first.
First, please check whether there is any visible damage to the package appearance. The
protective materials used for the package of the DVR can protect most accidental clashes during
transportation.
Then, please open the box and get rid off the plastic protective materials. Check whether there is
any visible damage to the DVR appearance.
At last, please open the machine crust and check the data wire in the front panel, power wire, the
connection between the fan power and the main board.
Note: Please carefully check the bottom or back on the product type and consistency. Label affixed
by the base plate or on the rear panel, Label, has a very important significance, please protect. When
contact with our customer service, will need you to provide label type and serial number.
2.2 The rack installation
The specification of machine box is standard 1U.It can be installed in the standard frame.
Installation approach and notice:
1、Mare sure the house temperature under 40℃(104°f).
2、Keep the DVR away from other equipments at least 15 centimeters(6 inches).
3、Frame installation from bottom to top.
4、If installing multiple components in the frame, take precaution to avoid the overload of the jack.
2.3 Understanding of the front panel
Front panel button operation function table (Note: This manual is a generic manual, Please
prevail in kind).
To Next Page
