Lifter 53
9 LIFTER
The tailgate can be equipped with a lifter, which is used to empty containers. Various lifters can
be mounted on the body, depending on the needs. There are three basic types of montage:
o exchangeable,
o permanent,
o nonstandard.
FOR YOUR INFORMATION
If using a body with a lifter, read and understand its operating instructions before use.
9.1.1 Technical data of lifters, according to EN 1501-5
Hydraulic connectors
Connector plug
ISO 7241-1 DN 25A
Connector socket
ISO 7241-1 DN 25A
Maximum working pressure
200 bar
Maximum volume flow
40-46 l/min
Electrical connector in the case of automatic lifting:
First electrical connector - pin diagram (permanently mounted on the body)
1
Type 1 (plus) power supply
2
Type (plus) power supply
3
Weight
4
Weight
5
Reverse gear
6
Lifter in lower position (not suitable for driving) + 24V
7
CleAN OPEN CAN L
8
EMERGENCY STOP circuit 1 - input
9
EMERGENCY STOP circuit 1 - output
10
EMERGENCY STOP circuit 2 - input
11
EMERGENCY STOP circuit 2 - output
12
Impulse for counting containers
13
Body ready for work
14
Hydraulic power request from the lifter to the vehicle
15
CleaANopen CAN-H
16
Activation of the compaction mechanism, request from the lifter
Total current consumption for electrical connectors = 8 A
