ZOJE ZJ5821 - Page 34

5. Basic Operating Instruction
Parameter
Code
Content Range
Default
Unit
Value
S08
Length of Linear Bar-tacking
2.0~6.0mm
（Each side at 3.0mm as
MAX）
0.1 5.0mm
S09
Stitch Number of Linear
Bar-tacking
5~18 Stitches 1 7 Stitches
S10
Stitch Number of Round
Bar-tacking
5~17 Stitches 1 7 Stitches
S11
Shape of Knife
1~6
（select the proper knife,
according to the different
knife code）
1 2
S12
Sewing Width Adjustment
-1.0~1.0mm 0.1 0.0mm
S13
Eyelet Part Low Speed
-600~0rpm
（This parameter takes
the default value of the
parameter 01 sewing
speed as standard.）
100 0rpm
S14
Speed of Linear Bar-tacking
1000~2500rpm
（if the sewing speed is
lower than the linear
bar-tacking speed, these
two speeds will become
equal.）
100 1800rpm
S15
Stitch Number of
Slow-start
0~3 stitches 1 0 stitch
S16
Speed of Slow-start
400~1500rpm
（if the sewing speed is
lower than the slow-start
speed, these two speed
will become equal）
100 700rpm
S17
Knife Adjustment in X
Direction
-0.5~0.5mm 0.05 0.0mm
S18
Knife Adjustment in Y
Direction
-0.7~0.7mm 0.05 0.0mm
S19
Stitch number of bar-tacking at
start
0~4 Stitches 1 0 Stitch
S20
Stitch number of bar-tacking
in end
0~4 Stitches 1 0 Stitch
S21 Adjustment in X Direction -1~6 1 0
25
