Replacement Parts
4-16 www.zoll.com 9650-000278-01 Rev. B
18 1887-000010-95-01
ASSEMBLY,BATTERY PACK,6.6 AH,14.8V
LITHIUM-ION,12- CELL CONDITIONED
19 9355-009041 DUAL HEAD VACUUM PUMP,M330 ASPIRATOR
20 1889-000004-01 ASSEMBLY, MANIFOLD, M330 ASPIRATOR
21 480-0144-00
HOSE BARB, NYLON, BLACK,
3/16" I.D. TUBE X 1/4-28 THD (MALE)
22 480-0226-00 HOSE BARB, 1/8"NPTM to 3/8" TUBE, 2 BARB
23 9320-001130 BRACKET,PUMP,M330 ASPIRATOR
24 357-0632-04
SCREW, PHILLIPS, FLAT HEAD, 6-32 x 1/4, STEEL, ZINC
PLATED, RoHS
25 9700-000002
MOUNT, VIBRATION DAMPING, NEOPRENE SANDWICH, F/F 8/
32 THREAD, W COUNTERSINK
26 9320-001134 CHASSIS, SAM, M330 ASPIRATOR
27 9320-001135 BRACKET,DOVETAIL STABILIZER,M330
28 357-0440-04
SCREW, PHILLIPS, FLAT HEAD, 4-40 X ¼, STEEL, ZINC
PLATED, RoHS
29 9330-002821 SPACER JAR,M330 ASPIRATOR
30 0163-000760
SCR, 8-32 X 5/8" LONG, PH, FLT, UNDERCUT, STAINLESS
STEEL
31 404-0EMV-41 BRACKET,CHASSIS,EMV
32 355-0832-04
SCREW, PHILLIPS, FLAT HEAD, 8-32 x 1/4, UNDERCUT, ZP,
RoHS
33 9310-005423 MUFFLER BLOCK,M330 ASPIRATOR
34 358-0632-06 SCREW, PHILLIPS, PAN HEAD, SS, 6-32 X 3/8
35 376-0007-00 WASHER, FLAT, #6, STEEL, ZINC PLATED, RoHS
36 9310-005427 FOAM,MUFFLER,M330 ASPIRATOR
37 9310-005424 OUTPUT BLOCK BAFFLE,M330 ASPIRATOR
Item Number
(called out in
picture)
ZOLL Part Number Part Description
