Replacement Parts
9650-000278-01 Rev. B ZOLL 330 Multifunction Aspirator Service Manual 4-17
38 0310-000375 O-RING, ID 1.614", OD 1.754" BUNA-N, A70 DUROMETER, BLK
39 340-0055-00
OIL-RESISTANT BUNA-N MULTIPURPOSE
O-RING, 2-3/8" x 2-1/2" x 1/16", RoHS
40 357-0832-48 SCREW, PHILLIPS, FLAT HEAD, 8-32 x 3, STEEL, RoHS
41 424-SPM1-21 PLATE,INTAKE
42 480-0226-00 HOSE BARB, 1/8"NPTM to 3/8" TUBE, 2 BARB
43 480-0181-00 TEE, BRASS, 1/8" NPTF
44 480-0132-00 NIPPLE, CLOSE, 1/8" NPTM X 1/8" NPTM , .500 LONG
45 480-0144-00
HOSE BARB, NYLON, BLACK,
3/16" I.D. TUBE X 1/4-28 THD (MALE)
46 9500-001907 TUBING,TYGON,CLEAR,3/16" x 5/16" x 1.0"
47 9500-001905 TUBING,SILICONE,WHITE, 5/16" x 9/16" x 5.5"
48 9500-001906 TUBING,TYGON,CLEAR,3/16" x 5/16" x 4.0"
49 9500-001904 TUBING,SILICONE,WHITE, 5/16" x 9/16" x 3.8"
50 9500-001903 TUBING,SILICONE,WHITE, 5/16" x 9/16" x 6.5"
51 1889-000022-01
VALVE, 2-WAY NC, MINIATURE HIGH FLOW
PROPORTIONAL,BRASS, 50 PSI, 5VDC,
¼” BARBS, WITH CONNECTOR
52 1889-000006-01 ASSEMBLY,TOP CONNECTOR,M330 ASPIRATOR
53 9500-001902 TUBING,SILICONE,WHITE, 5/16" x 9/16" x 2.6"
54 0163-000650 SCREW, #4-40 X 3/4"LG, PNH, PHL, SST
55 9500-001908 TUBING,TYGON,CLEAR,1/16" x 1/8" x 4.5"
56 9301-000807-01 ASSY, PCB, SAM, ASPIRATOR
57 334-0110-00 CLAMP, PLASTIC SLEEVE, 1/8" OD TUBING, NATURAL COLOR
Item Number
(called out in
picture)
ZOLL Part Number Part Description
