• You want to connect the router to your ADSL or cable modem, using your
Mobile Broadband modem as a backup Internet connection. See
The Basic
Setup Page (3G Failover) on page 35 for details.
• You want to set up QoS on your router. See
The QoS Page on page 51 for
details.
• You want to back up router settings that you made using the Configuration
Manager. See
The Backup Setting Dialog on page 58 for details.
Online Help
The Advanced program provides both online and context-sensitive help that guides
you in changing the settings on each menu.
• To access online help, click [HELP] on the menu's Toolbar. Each [HELP]
page describes the fields on the active page and, when applicable, the
required or recommended entries.
• The context-sensitive help automatically displays a question mark to the
right of the cursor, then opens a message box in the left pane of the page.
The message box contains text that describes the active field and its
required or recommended entry.
Launching the Configuration Manager's Advanced
Program
1 If you haven't already done so, plug the supplied Ethernet cable into the
Ethernet port on the router’s back panel and your computer’s Ethernet port.
2 Optionally, plug the Mobile Broadband USB modem into the router's USB port.
3 Turn on your computer and router, then launch your Web browser.
4 In the Web browser address bar, type the router's default IP address,
http://192.168.1.1 and then click
Enter to launch the Configuration Manager.
When the Configuration Manager's MAIN MENU opens, it displays a Status
page that summarizes the basic settings and current values for your setup.
5 On the Toolbar, type the login password --
admin is the default password -- in
the
System Password field, and then click Login.
6 Click Advanced on the Toolbar to launch the Advanced program.
34 Travel Router with Wireless-N User Manual
