Playback Screen
When the Home Screen is open, pressing to start playback will open this screen on the display.
This shows playback conditions of the H4essential, including playback time and recording file waveforms.
❶
Status icon
The playback status is shown by an icon.
• Playing back
• Paused
• Searching backward
• Searching forward
❷
Playback time
This shows the elapsed time since the start of playback.
❸
File length
This shows the length of the file currently playing.
❹
Remaining battery charge
This is shown when operating on batteries. When the remaining battery charge becomes low, replace
the batteries (→ Installing batteries) or connect an AC adapter (→ Connecting an AC adapter) or
portable battery (→ Using other power sources).
❺
Waveform display (built-in XY mic, inputs 1 and 2)
This shows the waveforms of the recorded files being played. The parts of the waveforms that have
already been played appear green.
The positions of marks can also be checked. (→ Adding marks during recording)
The input types are shown at the left end of each waveform.
• L: Built-in XY mic left channel
• R: Built-in XY mic right channel
18
