Setting phantom power
H4essential inputs 1 and 2 support phantom power and can provide +48 V. Turn on phantom power when
condenser mics that require it are connected.
This can be turned on/off separately for each input.
1. On the Home Screen, use to select (Input) and press .
This opens the Input Settings Screen.
2. Use to select the input for which you want to set phantom power and press .
, : Inputs 1 and 2
3. Use to select “Phantom”, and press .
4. Use to select On or Off, and press .
NOTE
When connecting devices that are not compatible with phantom power, do not turn on the phantom setting.
Doing so could damage the device.
48
