ProJet

x60 Series User Guide Troubleshooting the ProJet x60 Printers

5/12/13

Solution - Print Head

Troubleshoot using Section 7.3, ’Print Head Errors/Weak Parts’.

Solution - Motion Problems

• Clean the Fast Axis Rails. See Section 3.3, ’Clean The Fast Axis Rails and Carriage’.

7.10 Miscellaneous Problems

7.10.1 Vacuum Has Low/No Suction

Explanation: This is usually an indication that the Debris Separator needs to be emptied and cleaned, or

that the vacuum hose is plugged or damaged. Less commonly, the printer may have been turned off and

on too quickly. Always wait 1 minute after turning power off before turning it on again.

Solution:

• Debris Separator

• Remove the Debris Separator and empty the contents into a waste receptacle.

• Check that its gasket is not damaged. Also check that all four magnets are in place on the back of

the Separator. These magnets hold the Separator against the panel.

• When you replace the Debris Separator, ensure that it is flush against the panel.

• Vacuum Hose

• Check the vacuum hose is not plugged with debris.

• Check that the vacuum hose is not cut or torn.

• Power Cycling
